Rotary position sensor 55075-00

non-contactHall effectfor automotive applications

A robust, stainless steel threaded barrel Hall effect sensor with an M12 x 1mm pitch thread, 46mm (1.810") long, primarily used for geartooth sensing. Protected against severe and automotive environments. Capable of switching up to 27Vdc and 20mA. Available as 3-wire (voltage output) version with a range of sensitivity, cable length and connector options. Ideally suited for wheel, transmission and cam shaft speed sensing, geartooth sensors, rotary encoders, industrial, commercial and automotive applications. Features: • Rotary position geartooth sensor • Stainless steel M12 threaded barrel • Electronic protection against severe and automotive environments • Self-adjusting magnetic range • Three-wire (voltage output) sensor • Integral EMC protection (consult Littelfuse) • Integral short-circuit/reverse voltage protection • Available with a selection of cable length and connector options Benefits: • Long life, up to 20 billion operations • High-speed operation • No chopper delay • Unaffected by harsh environments • Rotary orientation not critical • On-chip 10-bit A/D converter Applications: • Geartooth sensors • Camshaft sensors • Linear and rotary encoders
