Swivel unit ZP-SE-9

Intermediate position module ZP-SE-9 Repeating accuracy: ± 0,01° Scope of delivery: Proximity switch, exhaust air flow control valve and cable with plug Application: for realisation of a third position with the swivel units SE-K-9 and SE-PI6-9 Setting range: ± 20° starting at 90° Cylinder-Ø: 1 x 63 mm Air consumption/double stroke: 186 cm³ Weight: 1,25 kg Drive: Compressed air (4 – 8 bar), steady, filtered (10 µm) and dried, lubricated or unlubricated Control: 5/2-way valve Connection: R1/8 Material of casing: High-strength aluminium, anodised Size: 9 Movement type: rotatory Movement group: swivel Price information: Due to price increases on the raw materials market, some items include a surcharge
