CNC milling-turning center INTEGREX e-V

vertical3-axisspindle

Highly rigid structure for stable high-accuracy machining Table enhanced with direct drive motor for high-torque and high-speed positioning Automation systems to meet your production requirements MAZATROL SmoothAi drives innovation for even higher productivity Wide range milling with double column construction Double column construction suitable for top face machining of large workpieces By taking advantage of the double column construction and the long X-axis stroke beyond the milling spindle, top face milling can be performed with only linear X- and Y-axis positioning, resulting in stable machining accuracy and higher productivity. High-power milling spindle and direct-drive table for turning Enhanced milling performance for high-productivity Three milling spindles are capable of machining a wide range of materials from steel to non-ferrous materials. All of them achieve compact size and high-power by adopting a built-in motor. High-torque, high-speed table (turning & C-axis) A direct drive motor that can output large torque in a compact volume is used to achieve both the high torque required for turning large workpieces and the high response that enables agile positioning. High-torque table (turning & C-axis) The turning spindle, driven by a high power motor and two-gear ranges, performs highly efficient machining of large diameter and heavy workpieces from rough machining to finishing. The C-axis can be indexed in 0.0001° indexing increments for high-accuracy machining. Flexible system expansion The system is scalable according to the production demands Different types of Mazak machines can be flexibly integrated into the system
