Stone cutting machine Fast 1 - 5

bladediamond

Overview
The Fast 1 is a thin-veneer cutting saw designed for irregular stone shapes. Equipped with a single diamond blade and a single cutting cycle, it is suitable for operators starting in veneer production or for small, short-run orders. The machine is optimized for fast, simple handling of rounded or irregular river stones and pebbles.

Operator and feeding
The machine includes a pusher bar that lets the operator load stones of varying thicknesses consecutively without pre-sorting. It handles thickness differences up to 120 mm (4 3/4 in), simplifying loading and saving time. Feeding is straightforward and requires minimal operator training.

Key features

• Single diamond blade configuration for a single cutting cycle
• Designed for irregular and rounded stones (river stones, pebbles)
• Pusher bar for consecutive loading of pieces with variable thickness (up to 120 mm)
• Simple operation suitable for small productions and introductory use
• Fast and flexible feeding process

Cutting parameters / Technical specifications

• Model: Fast 1
• Number of blades: 1 pc
• Max stone width: 300 mm
• Max stone height: 300 mm
• Blade diameter: 900 mm
• Thickness variation handled without pre-sorting: up to 120 mm (12 cm / 4 3/4 in)

Applications

• Cutting of irregular stones, river stones and pebbles
• Small series production, prototype runs or trial orders
