Band sawing machine Fast 5

for concretefor stone and concretefor stone

Overview
Fast 5 is an inline five-disc saw designed for high-productivity cutting of stone and concrete. The machine integrates a pressure bar that permits successive loading of workpieces with up to 12 cm thickness variation without prior thickness sorting, reducing loading time and operator effort.

Key capabilities

• Maximum workpiece height: 400 mm
• Maximum workpiece width: 300 mm
• Five discs in line for high throughput
• Support for different disc diameters on the same shaft (example: 600–1200 mm)
• Single slat conveyor eliminates need to synchronize two belts
• Conveyor speed up to 6 m/min
• Pressure bar allows up to 12 cm thickness difference between successive pieces

Operational features

• Single slat (lamella) conveyor for both back and workpiece feed
• Replaceable rubberized inserts fitted to belt shutters for improved grip and easy maintenance
• Shutter (lamella) design enables loading of heavy materials while maintaining high speeds
• Motorized disc heads with height adjustment from the control panel; position shown on machine touchscreen
• Integrated management system storing up to 40 recipes (material-specific cutting parameters)
• Work data logging with export capability to USB

Applications

• Cutting natural stone (marble, granite, etc.)
• Cutting concrete elements
• High-productivity production lines requiring repeatable cuts

Technical specifications

• Number of discs: 5 (inline)
• Maximum height: 400 mm
• Maximum width: 300 mm
• Maximum allowed thickness difference with pressure bar: 12 cm
• Supported disc diameters on same shaft: e.g. 600–1200 mm
• Conveyor: single slat (lamella) conveyor for back and workpiece feed
• Max conveyor speed: up to 6 m/min
• Disc heads: motorized, height-adjustable, measurement displayed on touchscreen
• Management system: stores up to 40 recipes
• Data export: work data exportable via USB
• Maintenance: replaceable rubberized inserts on belt shutters
