Band sawing machine Fast 3

for stone and concretehigh-capacityhigh-performance

Overview The Fast 3 is a thin veneer cutting machine equipped with three diamond in-line blades and the capability to mount blades of different diameters on the same spindle. It is engineered for continuous production and for producing multiple products or processing varied stone and concrete materials. Throughput capacity is approximately 30% higher than the two-blade Fast 2.

Feeding and loading A pusher bar allows the operator to load pieces with differing thicknesses up to 4 3/4" (120 mm) consecutively without preliminary thickness sorting, simplifying and accelerating loading operations.

Conveyor and mechanical advantages

• Single slatted conveyor belt used for both back support and feeding, eliminating the need to synchronize two belts.
• Easily replaceable rubber inserts fitted to the belt slats.
• Slatted design permits loading of heavy materials while maintaining high processing speeds.

Blades and measurement Blade heads are motorized for easy height adjustment and equipped with encoders; measurements are displayed on the machine touch screen for operator control.

Control and data management Integrated management system stores up to 40 recipes to save key cutting parameters per material. The system records work data which can be exported via USB for traceability and analysis.

Applications / Additional notes Suitable for continuous production, multi-product processing and cutting different stone and concrete materials. Supports configuring blades of different diameters on the same spindle and provides roughly 30% higher throughput compared with the two-blade Fast 2.

Technical specifications

• Commercial name: Fast 3
• Type: Thin veneer cutting machine
• Number of blades: 3 pcs
• Stone width (max): 300 mm
• Stone height (max): 400 mm
• Min-max blade diameter: 600–1200 mm
• Pusher bar: allows loading pieces with up to 4 3/4" (120 mm) thickness difference
• Conveyor: single slatted conveyor belt for back support and feeding, with replaceable rubber inserts
• Blade heads: motorized height adjustment with encoders
• Display: measurement read on machine touch screen
• Management system: stores up to 40 recipes; work data downloadable via USB
• Performance: throughput approx. 30% higher than Fast 2 (two-blade machine)
• Suitable for: continuous production, multi-product processing, different stone and concrete materials
