Laser cutting and engraving machine METALSELF LZ-3015P
for metalsheet metalthree-phase

Laser cutting and engraving machine - METALSELF LZ-3015P - METALSELF - for metal / sheet metal / three-phase
Laser cutting and engraving machine - METALSELF LZ-3015P - METALSELF - for metal / sheet metal / three-phase
Laser cutting and engraving machine - METALSELF LZ-3015P - METALSELF - for metal / sheet metal / three-phase - image - 2
Laser cutting and engraving machine - METALSELF LZ-3015P - METALSELF - for metal / sheet metal / three-phase - image - 3
Add to favorites
Compare this product
Go to the METALSELF website for more information

Characteristics

Technology
laser
Material
for metal
Product handled
sheet metal
Phase
three-phase
Configuration
double table
Other characteristics
with exchange table
X travel

1,500 mm
(59.06 in)

Y travel

3,000 mm
(118.11 in)

Z travel

150 mm
(6 in)

Cutting speed

Max.: 1.667 m/s
(5.469 ft/s)

Min.: 1.667 m/s
(5.469 ft/s)

Laser power

Max.: 60,000 W

Min.: 1,500 W

Repeatability

0.02 mm
(0.0008 in)

Acceleration

Max.: 9.81 m/s²
(32.19 ft/s²)

Min.: 9.81 m/s²
(32.19 ft/s²)

Power supply

Max.: 380 V

Min.: 380 V

Description

Overview
The METALSELF LZ-3015P is an industrial laser cutting machine with a two-table exchange platform designed to optimize production flow and minimize downtime.

Exchange platform and advantages
The core of the LZ-3015P is its two interchangeable work tables: while one table performs cutting operations, the other is available for loading/unloading. This enables continuous operation and improved production efficiency.
  • Superior processing efficiency: continuous cutting to maximize throughput.
  • Standby time savings: eliminates interruptions for loading/unloading.
  • Flexibility and adaptability: suitable for high-volume production and varied requirements.
  • Reduction of operating costs: decreased downtime increases overall yield.
  • Technical and performance benefits: high precision and speed for consistent results.

Main technical specifications of model LZ-3015P
The METALSELF LZ-3015P is built for high industrial performance and offers configurable parameters to suit various materials and thicknesses.
  • Standard cutting area: 3000 x 1500 mm (custom designs available).
  • Laser power: wide range, from 1500W to 60000W.
  • Axis travel X: 1500 mm.
  • Axis travel Y: 3000 mm.
  • Axis travel Z: 150 mm.
  • XY positioning accuracy: ±0.02 mm.
  • XY repositioning accuracy: ±0.02 mm.
  • Maximum XY positioning speed: 100 m/min.
  • Maximum X-Y acceleration: 1.0G.
  • Power phase: 3.
  • Rated voltage: 380V.
  • Frequency: 50/60 Hz.
  • Protection degree: IP54.

Services and support (commercial offer)
Pre-sales and after-sales services tailored for industrial use, with options for product customization and dedicated technical support.
  • Pre-sales services: personalized consultation, feasibility analysis, machine customization, inspections and acceptance (video or on-site via third parties).
  • After-sales service: on-site installation and assistance, remote support (video and online technical assistance), and rapid-response service during working hours to reduce machine downtime.
