LED stack light LED-TLM MINI ECO

steady3-color2-color

LED-TLM MINI ECO Series – Compact Tower Light Beacon for Local Status Indication The LED-TLM MINI ECO Series is designed for light commercial signalling applications where a compact, low-cost, and reliable local signal is required. Ideally suited for machine or process status indication, this static beacon stays permanently lit once powered (Single Stage Alarm). For enhanced versatility, it can be controlled remotely (e.g. via PLC or control panel) to create a flashing Second Stage Alarm when needed. Its modular design enables quick and easy assembly using a twist-lock system. Each LED module (available in red, amber, or green) includes quick-fit IDC connectors that push directly into male terminals. The beacon is available with two mounting options: a 100mm pole with mounting foot, or a 100mm pole with side-fix bracket. Each base is supplied with a 30cm flying lead for easy connection. Key Features • Module colours: red, amber, green • 8 ultra-bright SMT LEDs per module • Continuously rated • Static (optionally flashing when externally controlled) • Compact and cost-effective • Twist-lock modular assembly • Quick plug-in wiring with IDC connectors • Pole mountable with two bracket options • 360° light output around the vertical axis • Voltage: 12–24V DC • IP65 ingress protection Benefits • Affordable signalling solution for local indication • Fast, tool-free installation and wiring • Expandable to dual-stage alerts • Durable, weather-resistant housing Applications • Machine and process status indication • Panel-mounted signalling • Compact systems and automation lines • OEM equipment and workstations
