Helical gear gear reducer HA series

coaxialhollow-shaft500 - 1000 Nm

Designed to offer maximum reliability even in the harshest operating conditions, the HA product series guarantees complete versatility and is suitable for applications that require high radial loads. The H-series includes a large number of extremely versatile models, in cast iron (sizes 030 to 140) or aluminium (sizes A30 to A60) casing. Certifications Available: ATEX 3GD Warranty: Two years from date of delivery. Characteristics Sizes: A30-A40-A50-A60 Available versions: HA - fitted for motor coupling, IHA - with input shaft, CHA - with compact motor Casing with feet, flange F or universal U Gears hardened and tempered with shaved or ground profile Gearing with 1, 2 and 3 reduction stages Cases in die-cast aluminium alloy Load capacity calculated to ISO 6336 and verified according to AGMA 2001 Painted with RAL 5010 blue epoxy-polyester powder
