Guide roller FKY seriesstainless steel
Add to favorites
Compare this product
Characteristics
- Type
- guide
- Material
- stainless steel
- Outer diameter
52 mm, 62 mm, 72 mm
(2.047 in, 2.441 in, 2.835 in)- Inside diameter
15 mm, 20 mm, 25 mm
(0.59 in, 0.79 in, 0.98 in)- Load capacity
Max.: 66,000 N
Min.: 4,800 N
Description
Guide wheel with tapered roller bearings.
The sides of the race are convex
• On request, the guide rollers can be supplied with external parts in stainless steel (suffix NX) and with Viton seals for operating temperatures up to 120°C (suffix V), not available for dimension FKX 110 C. Internal rolling elements in standard bearing steel
• To prevent rotation between roller and shaft a pin can be fitted in one of the holes “d2” positioned in the side flange
• Pressure angle α for load calculation: guide rollers FKY 40° – guide rollers FKX 45°
• Standard seals: material NBR, RS type
