Polyethylene branch saddle SA3516 series

PEfor tubesbranch

Short description
Irrigation saddle clamp — galvanized saddle with PP clamp, 6-bolt configuration for 160 mm pipes.

Details

• Brand: KP
• Category: PP clamp saddles
• Model: SA3516
• Application: Tapping/branching in irrigation networks

Summary
Galvanized 6-bolt saddle clamp designed for secure tapping of PE/PP pipelines in agricultural irrigation systems.

Datasheet
Item code | d x g | Weight (g)
SA3516K160D | 160 x 1 | 1092
SA3516K160F | 160 x 1.5 | 1095.4
SA3516K160G | 160 x 2 | 1116.1
SA3516K160I | 160 x 3 | 1161.2
SA3516K160L | 160 x 4 | 1183.1

Technical specifications

• Type: PP clamp saddles
• Brand: KP
• Material: Galvanized saddle, PP clamp body
• Use: Irrigation pipeline tapping with 6-bolt fastening
• Available variants: SA3516K160D (160 x 1) - 1092 g; SA3516K160F (160 x 1.5) - 1095.4 g; SA3516K160G (160 x 2) - 1116.1 g; SA3516K160I (160 x 3) - 1161.2 g; SA3516K160L (160 x 4) - 1183.1 g
• Installation: Fit onto main line, align saddle and tighten bolts evenly; follow local standards for pressure testing and sealing
