Bolt pipe clamp SA3616 series

galvanised steelpolypropylenecorrosion-proof

Title
SA3616 - DOUBLE SADDLE GALVANIZED 6 BOLTS

Description
Double saddle clamp designed for irrigation pipeline connections. Metal saddle components are galvanized to resist corrosion; the clamp uses a 6-bolt fastening system for secure installation on PE/PP pipes.

Short description
Double saddle, galvanized finish, 6-bolt design for irrigation applications.

Product details

• Type: PP clamp saddles
• Brand: KP
• Category: PP clamp saddles
• SKU:

Summary
Galvanized double saddle with 6 bolts, available in multiple outlet sizes for irrigation systems.

Datasheet (table)
Item code | d x g | Weight (g)
SA3616K160D | 160 x 1 | 1111.2
SA3616K160F | 160 x 1"1/2 | 1121.7
SA3616K160G | 160 x 2 | 1174.7
SA3616K160I | 160 x 3 | 1280.1
SA3616K160L | 160 x 4 | 1394.2

Caractéristiques / spécifications techniques

• Product type: Double saddle, galvanized, 6-bolt design
• Intended use: Irrigation pipeline connections
• Material / finish: Galvanized metal components; PP saddle body
• Available configurations: SA3616K160D, SA3616K160F, SA3616K160G, SA3616K160I, SA3616K160L
• Outlet sizes (d x g): 160 x 1 ; 160 x 1"1/2 ; 160 x 2 ; 160 x 3 ; 160 x 4
• Weights (g): 1111.2 ; 1121.7 ; 1174.7 ; 1280.1 ; 1394.2
• Brand: KP
