Helical gear reducer ADR110
right anglehollow-shaft200 - 500 Nm

helical gear reducer
helical gear reducer
helical gear reducer
Add to favorites
Compare this product


Characteristics

Type
helical
Shaft orientation
right angle
Shaft configuration
hollow-shaft
Torque
200 - 500 Nm, 500 - 1000 Nm
Number of stages
single-stage, multi-stage
Performance
low-noise, low-backlash, high-performance, high-torque, high-efficiency, maintenance-free, high-rigidity
Applications
transmission, for servo motors, conveyor, for industrial applications, for robots
Other characteristics
compact, modular, flange, rugged, vertical
Rotational speed

Min.: 1 rpm
(6.28 rad.min-1)

Max.: 4,000 rpm
(25,132.74 rad.min-1)

1,500 rpm
(9,424.78 rad.min-1)

Power

Min.: 250 W
(0.34 hp)

Max.: 3,000 W
(4.08 hp)

1,500,000 W
(2,039.43 hp)

Description

ADR Series is our planetary gearbox with compact flange output shaft. You save more than a third of the space and benefit from a torsional stiffness that is five times higher than conventional products. Due to its standardized flange interface, it is especially easy to install. The integrated dowel hole provides additional secureness during fitting. Frame Size - 64mm, 75mm, 100mm, 140mm, 200mm, 255mm, 285mm Output Torque - 42Nm-4702Nm Ratio 1 stage - 3,4,5,6,7,8,9,10 Ratio 2 stage - 12,15,16,20,25,28,30,35,40,45,50 Ratio 3 stage - 48,60,75,80,100,120,125,180,200,256,320,512 Backlash 1 stage - P0<2 arc-min P1<3arc-min P2<5 arc-min Backlash 2 stage - P0<3 arc-min P1<5 arc-min P2<7 arc-min Backlash 3 stage - P0<5 arc-min P1<7 arc-min P2<9 arc-min
