Cable sock

Product Overview
Fiberglass Carbon Hybrid Sleeving is a braided tubular composite reinforcement combining carbon fiber and fiberglass yarns. The hybrid braid balances the stiffness and structural strength of carbon fiber with the impact resistance and cost-efficiency of fiberglass. The sleeve expands radially for installation over tubes, shafts and structural cores prior to resin infusion or curing, producing a lightweight, mechanically stable reinforcement once cured with compatible resins (epoxy, polyester, vinyl ester).

Key Features

• High tensile strength
• Improved impact resistance
• Enhanced fatigue durability
• Lightweight composite reinforcement
• Cost-effective alternative to pure carbon sleeves

What Is Fiberglass Carbon Hybrid Sleeving?
It is a tubular braided textile used to reinforce composite structures. By blending carbon and glass fibers in a single braid, the sleeve reduces brittleness compared with pure carbon sleeves while maintaining high stiffness. The braided design permits radial expansion for wrapping around tubes, shafts, pipes and structural cores before resin infusion or curing.

Key Technical Properties

• Fiber composition: Carbon fiber + Fiberglass
• Structure: Braided tubular sleeve
• Weight: Lightweight reinforcement
• Mechanical performance: Balanced stiffness and impact strength
• Compatibility: Epoxy, Polyester, Vinyl ester resins
• Diameter range: Customizable sizes available

Advantages Over Pure Carbon Fiber Sleeve

• Reduced brittleness under impact
• Improved crack resistance
• Lower material cost
• Better vibration damping
• Maintains structural rigidity

Typical Applications

• Composite drive shafts
• Automotive structural components
• Industrial rollers and shafts
• Sporting goods manufacturing
• Drone and UAV structures
• Marine composite parts

Manufacturing & Processing Notes
Suitable for vacuum infusion, resin transfer molding (RTM) and hand lay-up. Custom diameters, braid angles and carbon-to-glass ratios are available to meet engineering requirements. Thermal performance of the assembled composite depends on the chosen resin system.

Customization & OEM Options

• Custom diameters
• Adjustable braid angles
• Different carbon-to-glass ratios
• Roll length customization
• OEM packaging and labeling

Technical specifications

• Order (MOQ): 1
• Fiber composition: Carbon fiber + Fiberglass
• Structure: Braided tubular sleeve
• Compatibility: Epoxy, Polyester, Vinyl ester resins
• Diameter range: Customizable
• Weight: Lightweight reinforcement
• Mechanical performance: Balanced stiffness and impact strength
• Typical uses: Vacuum infusion, RTM, hand lay-up
• Customization: diameter, braid angle, carbon-to-glass ratio, roll length, OEM packaging
