Industrial bone band saw TG 515 VL

robustwith sliding table

Short description
Band saw with controlled feed system operated by handwheel, featuring a quick-release mechanism for fast table return. Designed for on-site cutting of aerated concrete blocks, poroton, ytong, gasbeton, wood-cement form blocks and hollow bricks. Special blade geometry minimizes noise and dust. A new clutch system ensures consistent cutting performance even in case of excessive table feed.

All models include

• Special upper and lower Widia blade guides
• Foldable workbench to reduce space during transport
• Suction port
• Lifting ring for crane handling
• Forklift pockets
• Electro-galvanized steel work table
• Rubber wheels for easy movement

Available models
TG 515 VL cutting height up to 50 cm

Paint finish
All our machines and equipment are powder-coated with epoxy-polyester thermosetting paints for excellent brilliance, weather resistance, and full environmental compliance.

Technical specifications

• Model: TG 515 VL
• Motor power (hp): 2
• Voltage (V): 230
• Cutting height (cm): 50
• Cutting length (cm): 66
• Table size (mm): 715 × 1060
• Table height from ground (mm): 750
• Dimensions (mm): 1050 × 900 × 1840
• Weight (kg): 220
