EDGE PC Helix 523

boxrack-mountVESA mounting

Description
The Helix 523 is a fanless industrial computer engineered for demanding edge deployments that require flexible I/O and modular expansion. It combines Intel® Core™ Ultra processing with two front-accessible ModBay slots to support a wide range of connectivity options and application-specific modules.

Highlights

• Dual ModBay expansion supporting additional LAN (1GbE/10GbE), PoE, M12, USB and serial options
• Intel Core Ultra processors for edge AI-capable compute
• Front I/O: 4x 2.5 GbE, 6x USB 3.2 Gen2 (Type A), 2x Thunderbolt 4 (USB-C)

Intel Core Ultra Performance
The Helix 523 is available with Intel Core Ultra processors (Series 1; Series 2 planned) optimized for edge AI workloads. The platform supports up to 96 GB DDR5 (5600 MT/s), M.2 storage (PCIe Gen4 and SATA), and optional Intel vPro-capable configurations for remote management and AMT features.

Engineered for industrial environments
With a fanless thermal design and compact low-profile chassis, the Helix 523 supports DIN, wall, VESA and rack mounting for space-constrained installations. The system meets industry EMC and safety standards and is certified for use in industrial, medical, in-vehicle, rail and maritime contexts. Operating temperature: 0 to 50°C.

Unrivaled I/O flexibility with ModBay
Two front ModBay slots provide modular connectivity: add 10 GbE, PoE-enabled RJ45, M12 LAN/PoE, COM ports, CAN, DIO or USB expansion depending on application. Front panel includes 4x 2.5 GbE, 6x USB 3.2 Gen2 Type A and 2x Thunderbolt 4; side/rear panels provide DisplayPort outputs and additional COM/CAN/DIO options.

Technical overview

• Model: Helix 523
• Brand: OnLogic
• Hardware line: Industrial (Fanless)
• Processor family: Intel Core Ultra (Meteor Lake / Arrow Lake)
• Processor options: Core Ultra 5 125H, 135H; Core Ultra 7 165H
• Memory: DDR5, up to 96 GB, 5600 MT/s, dual channel
• Front I/O: 6x USB 3.2 Gen2 (Type A), 2x Thunderbolt 4 (USB-C), 4x 2.5GbE LAN, audio jack, power button
• Rear/optional I/O: up to 4x COM (RS-232/422/485), CAN, DIO, 2x DisplayPort
• Expansion: 1x M.2 2280 M-Key (PCIe Gen4 x4), 1x M.2 B-Key, 2x front ModBay slots
• Storage: M.2 2242/60/80 B-key and M-key support
• Connectivity: optional 4G LTE, Wi‑Fi, Bluetooth
• Security & management: TPM 2.0 (Infineon SLB9672), optional Intel vPro
• Dimensions: 106 x 177 x 225 mm; Weight: 3.58 kg
• Power: 19–24 V DC via 4-pin terminal block
• Operating temperature: 0–50 °C
• Certifications: CE, FCC, UL/cULus, UKCA, RoHS, WEEE and relevant EMC/industry standards

Notes
LAN controller and I/O configuration vary by CPU and ModBay modules. Availability of features and regional certifications depend on configuration and country.

Technical specifications

• Model: Helix 523
• Brand: OnLogic
• Hardware Line: Industrial (Fanless)
• Processor: Intel® Core™ Ultra (selected SKUs)
• Memory: DDR5 up to 96 GB
• Storage: M.2 PCIe Gen4 and SATA options
• Front I/O: USB, Thunderbolt, 2.5GbE LAN
• Expansion: Dual ModBay, M.2 slots
• Power input: 19–24 V DC (4-pin terminal block)
• Mounting: DIN, wall, VESA, rack
