Radio receiver module RC-RFSK3-868

FSKwirelesscompact

FSK Radio receiver Module with PLL synthesizer and crystal oscillator, single line package with power down mode and RSSI output. - 4.8Kbit/s Version. Technical Characteristics: - Supply Voltage: 4.5V - 5.5V - Current Consumption (RX Mode): 5.7mA - 6.8mA - Current Consumption Shut Down Mode: max 100nA - Frequency: 868.35MHz - RF Sensitivity: -100dBm - Max Data Rate: 4.8kbit/s - RF Bandwidth 3dB: ±150KHz - Level of emitted spectrum: max -70dBm - Power Up Time from Power to stable data: max 8msec - Power Up Time from PD to stable data: max 5msec - Operating Temperature Range: -20°C to 80°C Pin Configuration: - 1: ANT - Antenna - 2: GND - Ground - 14: RSSI - RSSI Output - 15: GND - Ground - 16: VCC - Power Supply - 17: AF - AF Output - 18: OUT - Data Out Features: - FSK Radio receiver Module with PLL synthesizer and crystal oscillator - Single line package - Power down mode - RSSI output - 4.8Kbit/s Version
