2D scanning system VMX-3HA

for surface inspectionfor long-distance measurementsLIDAR

The RIEGL VMX-3HA is a High Speed, High Performance Dual Scanner Mobile Mapping System which provides dense, accurate, and feature-rich data at highway speeds. With 6,000,000 measurements and 800 scan lines per second, this turnkey solution is ideally suited for survey-grade mobile mapping applications. Built for professionals in transportation, infrastructure, and environmental mapping, the VMX-3HA Mobile Mapping System combines speed, precision, and efficiency in one powerful system – ready to take on complex projects with confidence. This powerful technology comprises two RIEGL VUX-3HA High Performance LiDAR Sensors and a high performance IMU/GNSS unit, housed in an aerodynamically-shaped protective cover.Interfaces for up to 9 optional cameras enable complementation of the LiDAR data with precisely geo-referenced images. 360° Precision in MotionWhether you're mapping city streets or highways, the VMX-3HA delivers full-environment coverage with pinpoint accuracy – even at high speeds. Ultra-Dense Data, Near and FarFrom fine pavement textures to overhead cables and distant vegetation, every detail is captured with clarity and depth. Effortless EfficiencyMaintain high point densities at faster platform speeds. The VMX-3HA keeps quality high and workflows smooth, even under demanding conditions. Main Features High laser pulse repetition rate (peak) of up to 6 MHz 2x up to 400 scans per second Max. measurement range 500 m Eye safe operation at Laser Class 1 Field of view 360° Multiple target capability Optional integration of up to 9 cameras Main Applications Road Surface Measurement Transportation Infrastructure Mapping City Modeling As-Built Surveying HD Mapping for Autonomous Vehicles Rapid Capture of Construction Sites and Bulk Material GIS Mapping and Asset Management Technical Data Overview Effective Measurement Rate2 x 300 kHz2 x 1000 kHz2 x 1800 kHz2 x 3000 kHz Max. Range, Target Reflectivity p ≥ 80%500 m280 m250 m200 m Max. Range, Target Reflectivity p ≥ 10%180 m100 m90 m70 m Minimum Range1 m1 m1 m1 m Max. Number of Targets per Pulse311585 Accuracy / Precision3 mm / 2 mm3 mm / 2 mm3 mm / 2 mm3 mm / 2 mm Software for RIEGL VMX-3HA RiPROCESS RiACQUIRE RiUNITE Special libraries: RiVLib, RDBLib Plugins: RiMAP Plugin for ArcGIS Characteristics / Technical Specifications High speed, high performance dual scanner mobile mapping system 6,000,000 measurements and 800 scan lines per second Two RIEGL VUX-3HA High Performance LiDAR Sensors High performance IMU/GNSS unit Aerodynamically-shaped protective cover Interfaces for up to 9 optional cameras 360° field of view Eye safe operation at Laser Class 1 Multiple target capability Effective measurement rate: up to 2 x 3000 kHz Max. range: up to 500 m (target reflectivity p ≥ 80%) Minimum range: 1 m Max. number of targets per pulse: up to 31 Accuracy: 3 mm Precision: 2 mm Optional integration of up to 9 cameras Applications: Road surface measurement, transportation infrastructure mapping, city modeling, as-built surveying, HD mapping for autonomous vehicles, rapid capture of construction sites and bulk material, GIS mapping and asset management
