Rotary positioner Rotary C Colon

6-axisfor robotsprecision

Overview
Robotic peripheral system designed to increase 6-axis robot accessibility and handling capabilities. The Rotary C Colon series is a single-rotary-axis positioner family produced for tailored dimensions and varying robot weights, enabling operators to handle different workpieces in low cycle times and improving robot accessibility in welding and automation cells.

Key properties

• Special manufacturing for desired dimensions and different robot weights
• Single rotary axis allowing handling of different workpieces with low cycle times
• Designed to increase robot accessibility where additional reach or orientation is required

Product positioning & features

• Gantry Robots compatibility
• High-Reach / High-Accuracy configurations available
• Rotary C Colon robotic peripherals produced for applications where robot accessibility must be increased

Customization & integration

• Additional options and accessories available to tailor solutions to specific needs
• Designed to integrate seamlessly with the robotic systems you already use (universal compatibility with leading industrial robot brands)
• Available in multiple colors to match branding or project requirements
• Option to customize products with customer branding
• Capability to deliver bespoke, customized designs to meet unique specifications

Technical specifications table
Size | Capacity (kg) | Welding Machine Options | Welding Wire Drum Options | Robot Drive Group | Maximum RPM of Axis
Small | 1000 | WM | WWD | OPTIONS | 6
Medium | 2500 | WM | WWD | OPTIONS | 4

Technical documents
Technical specifications PDF is available for download (technical specification file provided by manufacturer).

Characteristics / technical specifications

• Series name: Rotary C Colon
• Available sizes: Small, Medium
• Capacities: Small = 1000 kg, Medium = 2500 kg
• Maximum axis RPM: Small = 6 rpm, Medium = 4 rpm
• Welding machine option code: WM
• Welding wire drum option code: WWD
• Robot drive group: listed as OPTIONS (configurable)
• Special manufacturing to suit dimensions and robot weights (custom designs available)
• Universal compatibility with major industrial robot brands (integrates with existing robotic systems)
