Power chuck GD-RI 6 JAWS 2+2+2
6-jawmachiningself-centering

power chuck
power chuck
power chuck
power chuck
power chuck
Add to favorites
Compare this product


Characteristics

Type
automatic
Number of jaws
6-jaw
Other characteristics
machining, self-centering, hydraulic, large-diameter
Gripping force

Min.: 0 kN

Max.: 600 kN

Description

Self-centering chuck with 6 jaws linked by 2+2 for machining of big deformable diameter components like thin rings with simultaneous self-centerin action of the 6 jaws linled two by two in order to obtain a cententric clamping without structure traversing. The jaws are equipped with concentric movement and are linked by couples with the applicatin of the forces along the radial axis.The absence of anomalous resultant forces allows to keep the perfect circularity of the machined component. -Clamping stroke control device -Control by hysraulic cylinder and distributor with 3 manifolds+1 recovery

Catalogs

No catalogs are available for this product.

See all of ROTOMORS‘s catalogs
