Cut-off saw STS 647

for steelfor PVCPLC-controlled

Advantages • Standard design for cutting one overlap width and one cut height • For cutting of external overlap in line • 2 variants depending on the request and the support side: • Version with saw blade from the bottom for support inner surface down • Version with saw blade from above for support outer surface down 2 Positions: • in the cooling station (before cleaning) • in line (after the cleaning) Technical data Power (kW) : 3 Voltage (V) : 400 Operating pressure (bar) : 7 Cutting length (mm) min : 320 Cutting length (mm) max. : 1.900, 2.400 oder 2.900 Saw blade (mm) : 250 Height of cut (mm) : Execution of saw blade from below: 30 Cutting depth (mm) : 30 Machine dimension L x D x H (mm) : 2.750 x 1.614 x 3.655 (depending on specification) Weight (kg) : approx. 1.800
