Modular formwork SCAFFSHORE 60

slabbeamsteel

The SCAFFSHORE system permits the creatively easy, fast, flexible and safe assembly of shoring towers. No pipes and fittings required, stability of the system is achieved by the diagonal ledger bracing. Efficient Multiple propping head makes it possible to use steel, aluminum or timber decking Screw-jack head and base-jack allows for 80cm extension range for height adjustment The beam brackets allows for down stand support at any height inside the slab area Safe The web formation of the standards and ledgers are ‘locked’ together with ring lock Extreme stability against lateral forces thanks to the diagonal ledgers Safely sustains loads at slab-edges by means of cantilever frames Shorelok is a heavy duty modular steel shoring system designed for large shoring heights and high loads. With various well designed sizes in verticals, horizontals and an extensive range of accessories, shorelok is the first choice in modular heavy duly shoring. The system provides perfect adaptability to irregular layout with ease of assembly and low cost. Options for finish are available in painted or galvanized. Versotility To suit various site requirements the shorelok system is produced in two versions with compatible components: 9 The Shorelok 48, offers a shoring capability with an infinité height adjustment and a working load-carrying capacity of up to 40kN per leg with horizontal lifts of 1.5m. ^ The Shorelok 60, can be used efficiently and economically with an infinité height adjustment to transfer 75 kN SWL leg load with horizontal lifts of 1.5m • Extra load-bearing capacity can be generated by reducing horizontal ledger lifts. Easy to Handle
