Z-axis compensation module AGM-Z

robotic

Modular compensation unit with z-axis flexibility for the compensation of inaccuracies and tolerances as well as differences in height. As part of the AGM product family, the AGM-Z can be flexibly combined with the AGM-XY and AGM-W and therefore always offers the right compensation behavior for a wide range of applications. Advantages – Your benefits Highest bearing load capacity enables the handling of high loads and moments thanks to the ball guide Maximum flexibility thanks to the modularity of the AGM product family, combinations with XY and W are possible Locking for switching the unit rigidly in a defined, extended or retracted position Easily adaptable spring forces by manually reducing the springs Increased process stability by various sensing options via magnetic switches or inductive proximity switches The AGM-Z offers compensation in the z-axis, for example for removal and storage processes in any spatial orientation. Robust ball guides ensure maximum bearing load capacity when handling high loads and moments. The stiffness of the integrated pressure springs can be adjusted for optimal contact pressure forces during storage. This can be increased by additional actuation of the pneumatic cylinder. The modular and compact design enables combinations to be made, and saves installation height. The retracted and extended positions are monitored by magnetic switches or inductive proximity switches. 1 ISO mounting pattern on the robot and tool side, for easy mounting on most types of robots without needing an additional adapter plate
