TFT LCD display module YX24073A

transflective240 x 3202.4"

Description
The YX24073A is a 2.4-inch transflective TFT LCD display module designed for excellent sunlight readability, low power consumption and reliable operation in indoor and outdoor environments. Transflective technology uses a semi-reflective optical layer so reflected ambient light improves visibility under direct sunlight while the integrated white LED backlight provides vivid images in low-light conditions.

Key features

• 2.4-inch display with 240×320 (RGB) resolution
• Transflective TFT LCD for superior sunlight readability
• JD9852A driver IC with high-speed MIPI interface
• All O'Clock viewing direction for wide-angle visibility
• White LED backlight

Applications
Industrial handheld devices; smart utility meters; portable medical equipment; GPS navigation systems; agricultural electronics; battery-powered embedded products.

Basic Specifications
Item : Specification
Display Size : 2.4 inch
Display Technology : Transflective TFT LCD
Resolution : 240 (RGB) × 320
LCD Type : TFT-LCD / Transflective
Active Area : 36.72 × 48.96 mm
Outline Dimensions : 42.72 × 60.26 × 2.2 mm
Pixel Pitch : 0.153 × 0.153 mm
Viewing Direction : All O'Clock
Driver IC : JD9852A
Interface : MIPI
Backlight : White LED
Brightness : 200 cd/m² (Typ.)
Contrast Ratio : 800:1
Analog Operating Voltage : 3.2 V Typ.

Optical Characteristics
Parameter : Typical
Resolution : 240 × 320
Display Technology : Transflective TFT
Contrast Ratio : 800:1
Brightness : 200 cd/m²
Response Time : 25 ms
Color Gamut : 60%
Luminance Uniformity : 80%
Viewing Angle : 80° / 80° / 80° / 80°

Operating Conditions
Item : Range
Operating Temperature : -20°C ~ +70°C
Storage Temperature : -30°C ~ +80°C
Humidity : ≤90% RH (60°C)

Mechanical Drawing
Mechanical drawing available for the module (outline and mounting details provided in product resources).

Technical specifications

• Model: YX24073A
• Display size: 2.4 inch
• Resolution: 240 (RGB) × 320
• Display technology: Transflective TFT LCD
• Driver IC: JD9852A
• Interface: MIPI (high-speed)
• Active area: 36.72 × 48.96 mm
• Outline dimensions: 42.72 × 60.26 × 2.2 mm
• Pixel pitch: 0.153 × 0.153 mm
• Brightness (typ.): 200 cd/m²
• Contrast ratio: 800:1
• Backlight: White LED
• Viewing direction: All O'Clock
• Response time: 25 ms
• Color gamut: 60%
• Luminance uniformity: 80%
• Analog operating voltage: 3.2 V (typ.)
• Operating temperature: -20°C to +70°C
• Storage temperature: -30°C to +80°C
• Humidity: ≤90% RH (60°C)
