Steam industrial cooker ZD-XL 8600C
shrimpstainless steel

steam industrial cooker
steam industrial cooker
Add to favorites
Compare this product


Food product
stainless steel


Tunnel-type Shrimp Steaming Machine is used to cook live shrimps. Steam with high temperature, supplied from a boiler, heats the semi-closed interspace of Shrimp-steaming Machine. At the moment the temperature reaches a certain height level, conveying belt conveys live shrimps into its semi-closed interspace, and live shrimps hence will be heated to be well done. PS: a boiler is a must, and clients provide for themselves. This equipment mainly consists of a driving device, a transmission drum, a conveyer belt, a groove type upper supporting roller, a lower supporting roller, a rack, a sweeper, a tension device, a turnabout drum, a guide chute, an electric control device, etc. During working, the transmission hobbing is driven by the speed reducer to drive the conveyer belt through gear teeth, and the effect of shrimp cooking is achieved by reaching the required water temperature via a burner. It adopts a screw tension device for tensioning the conveyer belt, wherein the screw tension device also can adjust off tracking of the belt conveyor. ● The supporting legs, columns or platforms of the conveyor should be securely fixed onto the ground with chemical anchor bolts. ● All the mounting bolts for various parts of the rack should be tightened. Each supporting roller can be freely revolved. The axes of the supporting rollers, the transmission drum and the turnabout drum should be perpendicular to the longitudinal center line of the rack.
