Axial condenser
air-cooledaluminizedfor power generation

Axial condenser - SHUANGLIANG ECO-ENERGY SYSTEMS CO., LTD - air-cooled / aluminized / for power generation
Axial condenser - SHUANGLIANG ECO-ENERGY SYSTEMS CO., LTD - air-cooled / aluminized / for power generation
Axial condenser - SHUANGLIANG ECO-ENERGY SYSTEMS CO., LTD - air-cooled / aluminized / for power generation - image - 2
Axial condenser - SHUANGLIANG ECO-ENERGY SYSTEMS CO., LTD - air-cooled / aluminized / for power generation - image - 3
Axial condenser - SHUANGLIANG ECO-ENERGY SYSTEMS CO., LTD - air-cooled / aluminized / for power generation - image - 4
Axial condenser - SHUANGLIANG ECO-ENERGY SYSTEMS CO., LTD - air-cooled / aluminized / for power generation - image - 5
Add to favorites
Compare this product

Characteristics

Type
axial, air-cooled
Material
aluminized
Domain
for power generation

Description

Product overview
Direct Air-Cooled Condenser (ACC) system reduces cooling water consumption in power stations; applicable in water-scarce areas, water saving >85% compared with conventional water-cooled condensers.

Principle of operation
The ACC distributes exhaust steam from the steam turbine directly to each unit condenser via piping. Large axial fans draw ambient air across the tube bundles to remove heat. Steam condenses into water, which drains through bottom headers beneath the tube bundles to the condensate tank. An air evacuation system maintains vacuum across the ACC to ensure normal turbine operation and generation efficiency. The condenser combines parallel-flow tube bundles for main condensation and counter-flow tube bundles for extraction of non-condensable gases; both are connected via the bottom condensate tank.

Configuration and scope
  • Tube bundle
  • Air supply system (fans, ducts)
  • Air evacuation system
  • Condensate system
  • Cleaning system
  • Exhaust steam ducting system
  • Supporting structure
  • Draining system
  • Electrical system
  • Instrument & control system


Technical verification facilities
Three test devices
Performance testing device for tube bundles
Facility for heat transfer and on-line sampling tests of finned tube bundle structures. It measures heat transfer coefficients and wind resistance at varying air speeds and internal flow resistance at different steam velocities by simulating turbine back-pressures to verify thermal performance and pressure loss.

Environmental test laboratory: 1x4 ACC device
Laboratory can reproduce ambient conditions from 50℃ to -25℃ to simulate summer and winter ACC operation. Summer tests evaluate tube-bundle heat transfer; winter tests validate anti-freezing measures during start, stop and low-load operations and determine minimum anti-freezing steam flow at different temperatures.

Full performance hot-state test bed (single 1000MW unit)
Simulates main plant operating conditions to test ACC system performance including heat transfer, reliability, stability, economy, full-load summer capability and reliability of anti-freezing operation in winter.

Research topics
  • Heat exchange performance of heat exchanger components
  • Air-side resistance characteristics of heat exchanger components
  • Steam-side resistance characteristics inside heat exchanger tubes
  • Atmospheric corrosion performance of fins
  • Fouling behaviour of tube bundles
  • Tube-bundle fin flushing tests
  • Anti-freezing tests of tube bundles
  • Numerical simulation of direct air cooling systems
  • Fatigue testing of direct air-cooled tube bundles


Single-row tube design and advantages
Single-row tubes are made by welding aluminum serpentine fins to large flat tubes formed from single-side aluminum-clad plate, providing high thermal performance with the following features:
  • 01/ High heat transfer efficiency — Heat transfer area on both sides is fully utilized; steam-side circulation area is large, pressure loss is low and heat transfer efficiency is high.
  • 02/ Strong corrosion resistance — Outer surfaces of tubes and fins are aluminium alloys that form a protective alumina layer.
  • 03/ High strength and cleanability — Tube bundles are welded into high-strength integral structures for transport and installation; single-row fin channels allow linear flow and effective high-pressure washing without deformation.
  • 04/ Good anti-freezing performance — Large length-to-width ratio in base pipe sections ensures smooth condensate flow, reducing over-cooling and risk of freezing.


Technical specifications
  • Product name: Direct Air Cooled Condenser System (ACC)
  • Application: Replacement of water-cooled condensers in water-scarce areas; suitable for power stations
  • Water saving: Greater than 85% compared with conventional water-cooled systems
  • System components: tube bundle, air supply, air evacuation, condensate, cleaning, exhaust steam ducting, support structure, draining, electrical, instrument and control
  • Condenser configuration: Parallel-flow tube bundle for main condensation; counter-flow tube bundle for non-condensable gas extraction; connected via condensate tank
  • Advantages: Reduced footprint, multiple anti-freezing methods, flexible arrangement, high heat transfer efficiency, strong corrosion resistance, high structural strength, easy cleaning
  • Test and verification capability: Dedicated tube-bundle performance test device, environmental test laboratory (50℃ to -25℃ simulation), full performance hot-state test bed (simulates 1000MW unit conditions)
