Synchronization firmware

calculationanalysisconfiguration

Convince yourself of the unique and powerful firmware modules of the PICOSCALE Interferometers Firmware Modules The PICOSCALE provides a number of unique firmware modules that can be linked almost arbitrarily. Ultra-fast response times are realized as all modules directly run on the controller itself to easily set up complex experiments without programming software code. The clock generator, counter und stream generator module are included as standard. The other firmware modules are available upon request. We will be happy to advise you on the right choice. Fast Trigger Pulse Processing for: Synchronization with master clock of external devices Triggered data acquisition Alert system in case of unforeseen events, e.g. loss of optical signal, to be used as an emergency stop of external motion systems Real-time Data Processing for: Calculation of angles Scaling of results Output of position data via the GPIO interface within control loops Output of functions based on user defined look-up tables Arbitrary Function Generator for: Basic signal generator functionality (sine, square, sawtooth, custom) Excitation of targets and analysis of their frequency response with 1 mHz to 2.5 MHz Generate Your Own System Clock for: Timing of internal or external processes Generation of periodic trigger events with 1 mHz to 10 MHz Counter Module Used for: Counting of user defined trigger events Counting the clock pulses between trigger events Counting of system clock pulses for absolute timing of data Configuration of Data Stream to User PC: Up to 10 MHz data rate Many options to filter data Connected to trigger module for synchronized data acquisition
