Hydraulic cylinder CH serieswith piston roddouble-actingaluminum
Add to favorites
Compare this product
Characteristics
- Type
- hydraulic
- Technology
- with piston rod
- Configuration
- double-acting
- Material
- aluminum
- Other characteristics
- compact, lightweight
- Stroke
Max.: 100 mm
(3.937 in)Min.: 20 mm
(0.787 in)- Pressure
3.5 MPa
- Torque
Max.: 34 Nm
(25.077 ft.lb)Min.: 3 Nm
(2.213 ft.lb)- Speed
Max.: 0.1 m/s
(0.33 ft/s)Min.: 0 m/s
(0 ft/s)- Return speed
Max.: 100 mm/s
Min.: 8 mm/s
- Ambient temperature
Max.: 60 °C
(140 °F)Min.: -10 °C
(14 °F)
Description
・Lightweight, compact aluminum body
・It is possible to mount auto switches.
・Same longitudinal dimensions for cylinders with/without auto switches
・With auto switch (CHDQ series: CHDQ, CHDQW)
