Centrifugal fan CAMC-X serieswall-mountedextraction230VAC
Add to favorites
Compare this product
Characteristics
- Configuration
- centrifugal
- Type
- wall-mounted
- Function
- extraction
- Supply voltage
- 230VAC, 400VAC, 690 V
- Drive mechanism
- with asynchronous motor
- Material
- stainless steel
- Other characteristics
- belt-driven, backward curved, IP55, corrosion-resistant, ATEX
- Air flow
Max.: 2.08 m³/s
(73.455 ft³/s)Min.: 0.16 m³/s
(5.65 ft³/s)- Rotational speed
Max.: 2,930 rpm
(18,410 rad.min-1)Min.: 2,820 rpm
(17,719 rad.min-1)- Noise level
Max.: 94 dB
Min.: 73 dB
Description
Belt driven medium pressure fans, equipped with an electric motor, a standardised set of pulleys, belts and guards according to ISO-13857
Fan:
• Sheet steel casing.
• Backward curved impeller made of highly robust sheet steel, specially designed for dusty air and small suspended materials.
• Engine mounted on general bench.
• With inspection and cleaning hatch from size 560 and up.
• Maximum temperature of air to be carried: -25 ºC +90 ºC.
Motor:
• IE3 efficiency motors.
• Class F motors with ball bearings, IP55 protection.
• Three-phase 230/400 V 50 Hz (up to 4 kW) and 400/690 V 50 Hz (powers greater than 4 kW).
• Working temperature: -25 ºC +50 ºC.
Finish:
• Anti-corrosive finish in polyester resin, polymerised at 190 ºC, after degreasing with phosphate-free nanotechnology treatment.
On request:
• Special windings for different voltages.
• Fan prepared to transport air up to +300 ºC.
• Stainless steel fan.
• ATEX certified Category 2.
