Wall-mounted fan CASB-X seriescentrifugalextraction230VAC
Add to favorites
Compare this product
Characteristics
- Installation
- wall-mounted
- Configuration
- centrifugal
- Function
- extraction
- Supply voltage
- 230VAC, 400 VAC, 690 V
- Drive mechanism
- with asynchronous motor
- Material
- stainless steel
- Other characteristics
- ATEX, anti-corrosion, IP55, backward curved
- Air flow
Max.: 85,800 m³/h
(3,029,998.405 ft³/h)Min.: 3,950 m³/h
(139,492.934 ft³/h)- Rotational speed
Max.: 2,945 rpm
(18,504 rad.min-1)Min.: 975 rpm
(6,126 rad.min-1)- Noise level
Max.: 90 dB
Min.: 62 dB
Description
Belt driven high pressure fans, equipped with an electric motor, a standardised set of pulleys, belts and guards according to ISO-13857
Fan:
• Sheet steel casing.
• Backward curved impeller made of highly robust sheet steel, specially designed for dusty air and small suspended materials.
• Engine mounted on general bench.
• With inspection and cleaning hatch from size 560 and up.
• Sizes larger than 1600 will be supplied with split casing to facilitate transport.
• Casing continuously welded from size 710 and up.
• Maximum temperature of air to be carried: -25 ºC +120 ºC.
Motor:
• IE3 efficiency motors.
• Class F motors with ball bearings and IP55 protection.
• Three-phase 230/400 V 50 Hz (up to 4 kW) and 400/690 V 50 Hz (powers greater than 4 kW).
• Working temperature: -25 ºC +50 ºC.
Finish:
• Anti-corrosive finish in polyester resin, polymerised at 190 ºC, after degreasing with phosphate-free nanotechnology treatment.
On request:
• Special windings for different voltages.
• Fan prepared to transport air up to +300 ºC.
• Stainless steel fan.
• ATEX certified Category 2.
