45° slant bed in cast iron
with 4 prismatic dlides
EQUIPMENT
Ø200mm chuck with concentric jaws, delivered with:
1 set of 3 hardened jaws
1 set of 3 ground jaws
Tailstock MK4
Automatic rear turret VDI 40, 12 stations
Rotating tools and C axis
Y axis
Sliding and swiveling operator console
Chip conveyor
3 bar coolant system
Sliding front door and security lock for full protection
Automatic volumetric greasing
interior lighting
Ventilated electrical cabinet
Status light
OPTIONS:
rollers for Ø50mm to 250mm, manual adjustment
Fix steady rest with 3 rollers for Ø250mm to 400mm, manual adjustment
Tool probe
Isolation transformer
FAGOR 8065 CNC with Learning SOMAB PL+S VT
15" color LCD flat touch screen
QWERTY alphanumeric keyboard
Two handwheels
Rigid tapping (fixed tools and rotating tools)
USB connections on front panel
Connection to ETHERNET network with RJ 45, 3 operating modes
conversationally
Learning Mode Manual
ISO mode
4 Gb Memory
Tools Library
Visualization of cutting forces - oscilloscope
working with .dxf files
or
SIEMENS 828 D with Conversational SHOPTURN
10.4" TFT flat color screen
Full QWERTY alphanumeric keyboard
An electronic handwheel
Rigid tapping
USB connections on front panel
Connection to ETHERNET network with RJ 45
