Lever-operated manipulator LEV01 / LEV02

with integrated hooktooltransport

Overview
Drum lever bars provide a safe, low-effort method to rotate and position heavy 200–220 litre steel drums on pallets or the ground. The tool clips to the drum upper rim and uses 1.2 m of mechanical leverage to orient bungs/caps and safety labels or to separate and combine drums without lifting.

Key features

• Designed for 200–220 litre steel drums
• Clips securely to the drum upper rim for positive engagement
• 1.2 m of leverage to minimise operator effort
• Manual input force required: less than 20 kg
• Enables precise orientation of bung/cap and safety labels
• Permits safe separation and combination of drums on pallets

Models

• LEV01 — for tight-head (permanently sealed) steel drums
• LEV02 — for open-head (removable lid) steel drums

Drum suitability
LEV01 is compatible with 200 litre tight-head steel drums. LEV02 is compatible with 200–220 litre open-top steel drums. Use the lever to position drums on pallets, bunds or storage locations; it is not designed to remove drums from a pallet by lifting.

Benefits

• Reduces manual handling effort and the risk of related injury
• Allows precise alignment of bungs/caps and safety labels for handling and inspection
• Provides controlled separation and combination of drums for safe processing
• Low operator input force increases productivity during positioning tasks

Product media and documentation
Instruction manual and drum suitability technical documentation (PDF) are available for both models.

Specification table (summary)
Drum compatibility: Tight-head and open-head steel drums in the 200–220 litre range (model dependent)
Manual force required to operate: less than 20 kg
Lever length / mechanical advantage: 1.2 m
Adjust drum position on a pallet: Yes
Orientate bung/cap: Yes
Orientate safety labels: Yes
Remove drums from pallet: No

Technical characteristics

• Model designation: LEV01 / LEV02
• Intended drum sizes: 200–220 litre steel drums
• LEV01: for tight-head (sealed) steel drums
• LEV02: for open-head (removable lid) steel drums
• Lever length / mechanical advantage: 1.2 m
• Required manual input force: less than 20 kg
• Functions: rotate drums on pallets or ground; orient bung/cap; align safety labels; separate/combine drums
• Not suitable for removing drums from pallet by lifting
• Documentation: operating instructions and drum suitability technical specification available (PDF)
