Trimming machine AV2 NET 4.0

Product overview
The AV2 NET 4.0 is an electronic skiving machine designed for precise skiving of soft materials at a single thickness. Features include an advanced PC HMI, QR code support, infinite program storage and remote connectivity for transferring work parameters between the machine and the office. Skiving width is 45 mm. Versions B, C and D can be fitted with an optional variable speed drive with electronic adjustment.

Available versions

• Version A – head only; dimensions 38 x 54 x 40 cm; weight 38 kg
• Version B – with table and motor; dimensions 115 x 105 x 55 cm; weight 93 kg
• Version C – with table and motor plus exhauster; dimensions 115 x 105 x 55 cm; weight 95 kg
• Version D – with table, loading motor and super exhauster; dimensions 115 x 105 x 55 cm; weight 102 kg

Business fields

• Synthetic materials
• Textile
• Leather
• Felt

Manufacturing sectors

• Footwear industry
• Leather goods industry
• Upholstery
• Clothing

Options
A wide range of knives, guides and spare parts is available and in stock. Variable speed drive is available as an option for versions B, C and D (electronic adjustment).

Technical specifications

• Commercial model name: AV2 NET 4.0
• Type: Electronic skiving machine (4.0)
• Skiving width: 45 mm
• Program storage: Infinite stored skiving programs
• User interface: Advanced PC HMI with QR code support
• Connectivity: Remote control and transfer of work parameters between machine and office
• Materials: Dedicated to skiving soft materials at one thickness
• Versions & dimensions/weights: Version A — 38 x 54 x 40 cm (38 kg); Version B — 115 x 105 x 55 cm (93 kg); Version C — 115 x 105 x 55 cm (95 kg); Version D — 115 x 105 x 55 cm (102 kg)
• Options: Variable speed drive (optional for B, C, D) with electronic adjustment
• Spare parts & accessories: Wide range of knives and guides available in stock
