Arbitrary waveform generator P1282M
dual-channelcompactPXIe

arbitrary waveform generator
arbitrary waveform generator
Add to favorites
Compare this product


Characteristics

Type
arbitrary waveform
Other characteristics
dual-channel, compact, PXIe

Description

The Proteus P1282M, is a PXIe based, 1.25GS/s, dual channel arbitrary waveform generator. The P1282M offers industry leading performance Including an innovative task oriented programming, real time data streaming, fast feedback loop for environment dependent waveform generation and user customizable FPGA for application specific solutions. Highlights • - Dual channel 1.25GS/s AWG • - Dual channel, 8GHz Bandwidth, 2.7GS/s 12 bit digitizer • - Integrated NCO for digital upconverting to microwave frequencies • - Excellent phase noise and spurious performance • - Feedback control system for conditional waveform generation • - Modular PXI Express platform, easily scalable to hundreds of channels. • - High speed PCIe GEN3 x8 lanes communication interface • - Up to 16GS waveform memory with the ability to simultaneously generate and download waveforms • - Real time data streaming directly to the FPGA for continuous and infinite waveform generation • - User customizable FPGA for demodulation, digital filtering and application specific solutions • - Innovative task oriented sequence programming for maximum flexibility to generate any imaginable scenario
