Heat sink enclosure AWN seriesdesktoprectangularextruded aluminum
Add to favorites
Compare this product
Characteristics
- Construction
- desktop
- Configuration
- rectangular
- Material
- extruded aluminum
- Application
- industrial, for controllers, for sensors, for power supplies, for measuring devices, for remote control
- Protection level
- heavy-duty, IP68, EMC-shielded, EMI-shielded, for harsh environments
- Other characteristics
- heat sink
- Width
Min.: 54.6 mm
(2.1 in)Max.: 206.3 mm
(8.1 in)- Height
Min.: 34.6 mm
(1.4 in)Max.: 86.3 mm
(3.4 in)- Depth
Min.: 65 mm
(2.56 in)Max.: 310 mm
(12.2 in)
Description
Rugged IP68 and heat dissipation enclosure. Available in both Normal and EMC Shielded types.
The extruded aluminium frame and diecast aluminium panels make it extremely suitable to be used in harsh environments where waterproofing and heat dissipation is essential.
PCB or chassis can be mounted by sliding it horizontally into the body frame with grooves on the inside.
Suitable for measuring instruments, industrial control boxes, industrial camera housings, and other applications.
Specifications
See TAKACHI website for accessories and optional parts.
The extruded aluminium frame and diecast aluminium panels make it extremely suitable to be used in harsh environments where waterproofing and heat dissipation is essential.
PCB or chassis can be mounted by sliding it horizontally into the body frame with grooves on the inside.
Suitable for measuring instruments, industrial control boxes, industrial camera housings, and other applications.
Specifications
- Material : Diecast aluminium ADC12, extruded aluminium A6063S-T5
- Protection class : IP68 (withstands immersion in water up to 1m for 24 hours)
- Operating temperature : -40°C ~ +105°C
- EMC shielded models available.
- 34 sizes available.
- Available in 4 color combinations.
See TAKACHI website for accessories and optional parts.
