Control electrical enclosure DW serieswall-mountedverticalaluminum
Add to favorites
Compare this product
Characteristics
- Function
- control
- Configuration
- wall-mounted, vertical
- Material
- aluminum
- Protection level
- waterproof, EMC
- Application
- industrial, outdoor, for telecommunications
- Other characteristics
- for harsh environments
- Width
Min.: 100 mm
(3.9 in)Max.: 140 mm
(5.5 in)- Height
Min.: 60 mm
(2.4 in)Max.: 100 mm
(3.9 in)- Depth
Min.: 150 mm
(5.91 in)Max.: 220 mm
(8.66 in)
Description
IP68 high performance diecast aluminium box which withstands immersion in water up to 1m for 24 hours.
EMC shielding is achieved with the unfinished inner sides of the top cover and base, as well as the conductive silicone gasket.
This enclosure is suitable for use in severe environment such as for outdoor network devices, plant control equipment, meteorological instruments and more.
Specifications
See TAKACHI website for accessories and optional parts.
EMC shielding is achieved with the unfinished inner sides of the top cover and base, as well as the conductive silicone gasket.
This enclosure is suitable for use in severe environment such as for outdoor network devices, plant control equipment, meteorological instruments and more.
Specifications
- Material : ADC12 aluminium die-cast alloy
- Protection class : IP68
- Operating temperature : -40°C ~ +105°C
- EMC shielded
- 4 sizes available.
- Available in White.
See TAKACHI website for accessories and optional parts.
