Extraction unit with air monitoring GL DESK-Serie

dustgasodor

Product overview
The GL-Desk series is a compact extraction substructure designed to accommodate and support compact laser systems with a maximum footprint of 700 x 700 mm. The Green Line blower is energy-saving and noise-reduced, enabling significant energy savings compared to equivalent extraction technology. The unit can be used as a substructure under laser equipment and can replace a separate worktable.

Key features

• Space-saving substructure for installation of compact laser systems
• Supports maximum laser footprint: 700 x 700 mm
• Energy-saving Green Line blower — up to 65% energy savings vs. equivalent extraction technology
• Low operating noise: approx. 53 dB(A)
• Front-access doors with individually replaceable filters for easy maintenance
• Contamination-reduced dust disposal

Filtration and air treatment

• Filter configuration: Z-LinepanelPlus F7 + particulate filter H13 + activated carbon (variable capacity by model)
• Molecular sieve option for gaseous pollutants
• Optional activated carbon granules for increased adsorption capacity
• Selectable air routing: recirculation or exhaust-air duct

Control and options

• Full control interface for permanent monitoring and system control
• Modular filter set-up to match application requirements

Models

• GL-Desk 20 / 30

Technical specifications

• Series: GL DESK series
• Maximum laser footprint supported: 700 x 700 mm
• Maximum volumetric flow: 350 m³/h
• Effective volumetric flow: 100 – 300 m³/h
• Maximum static pressure: 6000 Pa
• Voltage: 100–240 V
• Frequency: 50/60 Hz
• Motor power: 0.6 kW
• Operating noise (approx.): 53 dB(A)
• Filter access: front doors, individually replaceable
• Dust disposal: low-contamination
• Gaseous pollutant treatment: molecular sieve (optional)
• Adsorption option: activated carbon granules (optional)
• Airflow options: recirculation or exhaust-air duct
• Serial interface: Sub-D 25-pin
