Extraction unit with air monitoring DT-Serie

laboratorygasdust

Overview
The DT series extraction cabinet is specially designed for laboratory and workshop use. It is intended for local extraction during painting and bonding operations, featuring a height-adjustable work surface and an adjustable protective screen. The system is suitable for extraction of particles and gases and can be supplied in an ATEX variant for use in zone 2 (gases) and zone 22 (dust).

Key features

• Height-adjustable work surface (max. 100 mm)
• Adjustable protective screen for targeted extraction
• ATEX variant for zone 2 (gases) and zone 22 (dust)
• Captures particles and gaseous pollutants
• Low-contamination dust disposal
• Optional molecular sieve for gaseous pollutants
• Air recirculation or exhaust air duct options
• Process-dependent, individually configurable filter equipment
• Filter saturation monitoring via differential pressure indicator
• Optional activated carbon granules for increased adsorption

Models
DT 100 / DT 150

Functionality and suitability
The DT series provides safe local extraction with an adjustable protective screen and height-adjustable work surface to optimize operator ergonomics for painting and bonding tasks. Systems are configurable to meet process-specific filtration and disposal requirements, including molecular sieve and activated carbon options for gaseous pollutants.

Technical specifications

• Series name: DT series
• Application: laboratory and workshop extraction for painting and bonding processes
• ATEX suitability: zone 2 (gases) and zone 22 (dust)
• Height adjustment: work surface adjustable up to approx. 100 mm
• Protective screen: adjustable for targeted extraction
• Filtration options: configurable filters; molecular sieve for gases; optional activated carbon granules
• Air handling: selectable air recirculation or exhaust air duct
• Dust disposal: low-contamination dust disposal
• Configurability: system configurable to process-specific requirements
• Representative models: DT 100, DT 150
