PTC temperature sensor 1SN0144
Add to favorites
Compare this product
Characteristics
- Technology
- PTC
- Temperature
Min.: 60 °C
(140 °F)Max.: 190 °C
(374 °F)
Description
Sensor suitable for detecting the winding temperature of the electric motor or transformer.
In accordance with DIN 44081 and 44082 rules
Fast response type
Cable in PTFE (std 3 m) further lengths on request
Ø of the sensor: 3 mm
Lead cross-section: 0,14 mm2
Dielectric test Ueff 2500V
