with thermometer, with data logger, with insulation tester, harmonic
Other characteristics
AC/DC, true RMS, autorange
Max DC voltage
999.9 V
Max AC voltage
999.9 V
Max DC current
10 A
Max resistance measure
50,000 kOhm
Max capacity measure
9,999 µF
Max frequency measure
9,999 kHz
Max DC voltage resolution
0.1 V
Max AC voltage resolution
0.1 V
Max DC current resolution
1 mA
Max resistance resolution
10 kOhm
DC voltage precision
0.05 %, 0.1 %
AC voltage precision
1 %
DC current precision
0.2 %
Resistance precision
0.2 %, 2 %, 5 %
Process temperature
Max.: 1,200 °C (2,192 °F)
Min.: -40 °C (-40 °F)
Length
193 mm (7.6 in)
Width
91 mm (3.58 in)
Height
53 mm (2.09 in)
Weight
470 g (16.58 oz)
Description
• Variable — frequency drive (VFD) V & Hz measurement.
• Lo — Z voltage measurement to drain ghost voltages.
• Check 3 phase sequence.
• Voltage harmonic ratio measurement.
• Smart ohm for ground resistance measurement.
• Data hold & Auto hold mode.
• Max/Min/Avg record mode.
• Relative value display.
• Frequecy count. (Auto-Range)
• Temperature type K, J measurement.
• Capacitance measurement.
• Data memory & read ftinction.
