Float level switch 3800 for liquidsfor tankstainless steel
Add to favorites
Compare this product
Characteristics
- Technology
- float
- Medium
- for liquids
- Applications
- for tank
- Material
- stainless steel, PVC
- Other characteristics
- reed switch, intrinsically safe
- Process temperature
Max.: 140 °F
(60 °C)Min.: -40 °F
(-40 °C)- Process pressure
50 psi
Description
Specific gravity .7 minimum.
Operates in 5/8″ envelope. Actuates in approximately 1/4″ of water level.
Wetted parts: stainless steel, PVC, hysol epoxy, and cunife magnet.
Use in flammable environments. Should only be used with an intrinsically safe barrier to make the sensor safe not posing a hazard.
Model 3800 switch logic is the same N. C. (normally closed) tank dry condition in either side unit is installed.
Switch logic N.C. (normally closed) tank dry. Switch opens on increasing level.
