Underground mining utility vehicle Adroit 520AH-2

dieselself-propelled4-wheel drive

Overview
Adroit 520AH-2 is a 4×4 self-drive articulated basket platform designed for combined basket and fork operations. Built to EN280, it is powered by a Deutz 103 kW Euro Stage III diesel engine and uses a Dana 4×4 hydrostatic drivetrain axle and transmission. The machine is fitted with an S.A.H.R braking system enabling 40% gradient climbing and multiple safety systems including stabilizer cylinders, automatic basket and fork stabilization, momentum sensing and overload sensing.

Key features

• 1500 kg + 2 personnel boom lift capacity
• Max. lifting height 5.72 m (basket)
• Max. lifting height 5.6 m (fork attachment)
• Equipped with fork attachment and quick coupler
• Deutz 103 kW Euro Stage III diesel engine
• Dana 4×4 hydrostatic drivetrain and transmission

Operation & use
Quick coupler enables single-person changeover between basket platform and fork attachment. The vehicle's self-drive articulated frame and hydrostatic drive offer controlled maneuverability in confined or uneven underground environments. With a Stage 2 FOPS and ROPS certified cabin, the Adroit 520AH-2 is suited for mines, metro tunnels and other underground operations such as ventilation, electro-mechanical installations and injection or explosive-access tasks.

Safety & compliance
Manufactured in compliance with EN280. Safety equipment includes stabilizer cylinders, automatic basket and fork stabilization, momentum sensing, overload sensing and reinforced S.A.H.R braking to support steep-gradient operation (up to 40%).

Technical specifications

• Model: Adroit 520AH-2
• Function: 4×4 articulated basket platform with fork attachment
• Lifting capacity: 1500 kg + 2 personnel (boom lift)
• Max. lifting height (basket): 5.72 m
• Max. lifting height (fork): 5.6 m
• Engine: Deutz 103 kW Euro Stage III diesel
• Drivetrain: Dana 4×4 hydrostatic drivetrain axle and transmission
• Drive system: Hydrostatic
• Brakes: S.A.H.R brake system (up to 40% gradient)
• Safety systems: stabilizer cylinders; automatic basket and fork stabilization; momentum sensing; overload sensing
• Cabin protection: Stage 2 FOPS and ROPS certified cabin
• Quick coupler for single-person attachment change
• Standards: EN280 compliance
