Rugged housing
Protection class IP67
Diagnosis display for status and error indication
Scan field L: 1260 mm
Optical Alignment aid
No blind zone
Range: 0.1…12 m
Resolution: 14 mm
Operating voltage: 24 VDC
No restart interlock
Safety light curtain type 4 acc. to IEC 61496-1 and 61496-2
Category 4 Ple acc. to EN ISO 13849-1
SIL 3 acc. to IEC 61508 SIL 3 and CL3 acc. to IEC 62061
Shock and vibration resistant acc. to IEC 61496-1
Country of origin - MX
Weight - 7620 g
Technical Data
Function - Light screen
Design - Rectangular
Scan field - 1260 mm
Range - 100…12000 mm
Optical resolution - 14 mm
Number of beams - 144
Light type - IR
Cascadable - No
With muting function - no
Start/Restart interlock - no
Output function - 2 normally open contact, 2 × PNP
Electrical connection - Cable with connector, M12 × 1
Cable length - 0.30 m
Housing material - Metal, AL, Yellow polyester
Ambient temperature - -20…+55 °C
