Plug valve 01FP
pneumaticangle seatATEX

Plug valve - 01FP - VALVOLE Hofmann by BONINO Engineering srl - pneumatic / angle seat / ATEX
Plug valve - 01FP - VALVOLE Hofmann by BONINO Engineering srl - pneumatic / angle seat / ATEX
Add to favorites
Compare this product

Characteristics

Type
plug
Operation
pneumatic
Body
angle seat, ATEX
Applications
actuator, shaft
Material
PEEK, PTFE, stainless steel
Other characteristics
ANSI, DIN, normally closed, ATEX
DN

Min.: 15 mm
(0.591 in)

Max.: 65 mm
(2.559 in)

Pressure

Min.: 6 bar
(87 psi)

Max.: 8 bar
(116 psi)

Temperature

Min.: -15 °C
(5 °F)

Max.: 225 °C
(437 °F)

Description

Body in microcast stainless steel CF8M/316 Actuator in stainless steel AISI 304 Normally-closed, normally-open, double-effect function Seal in modified PTFE or PEEK Packing in PTFE and FPM Guided shaft for stable axial movement Self-centering plug to ensure perfect positioning Connections: BSPP – NPT – BW – SW – DIN/ANSI flanges
