Transimpedance amplifier FIP series

compactAC

FIP is a series of high speed, transimpedance, AC coupled amplifiers, intended to operate with biased TE-cooled IR detectors. They enable precise I-V conversion, detector biasing up to -800 mV and simultaneously maintains compact size and keep current noise low. FIP amplifiers are equipped with a fan and does not require any additional heat dissipation. They are suitable for applications requiring wide frequency bandwidth. Additional DC output is available as an option. Features Compatible with VIGO TE-cooled, biased IR detectors in the TO8 package Frequency bandwidth: up to 1 GHz AC coupled (DC monitor as an option) M4 mounting hole Designed for effective heat dissipation Integrated fan External TEC controller required
