Volume pneumatic booster BO 7,5

pressure

Description
The piston air booster BO 7,5 is designed to increase compressed air pressure in industrial installations where higher working parameters are required. The unit operates over a 15–40 bar range, making it suitable for systems that require intensified compression following an initial compression stage.

Motor and performance
The model is equipped with a 7.5 kW motor, ensuring stable and efficient operation under industrial conditions. Depending on inlet pressure 7 / 10 / 13 bar, the unit delivers 2.10 / 2.89 / 3.67 m3/min, allowing adaptation to different compressed-air system configurations and process demands.

Design and application
Compact construction with dimensions 1286 x 825 x 753 mm and a weight of 268 kg enables straightforward installation in technical rooms and on production lines. The unit is designed for continuous operation, providing stable pressure boosting in pneumatic systems.

Technical data
Pressure (bar): 15-40
Inlet pressure (bar): 7 / 10 / 13
Power (kW): 7.5
Flow rate (m3/min): 2.10 / 2.89 / 3.67
Weight (kg): 268
Length (mm): 1286
Width (mm): 825
Height (mm): 753

Features / technical specifications

• Application: boosting compressed air pressure in industrial installations
• Operating pressure range: 15–40 bar
• Inlet pressure options: 7 / 10 / 13 bar
• Motor power: 7.5 kW
• Flow depending on inlet pressure: 2.10 / 2.89 / 3.67 m3/min
• Mass: 268 kg
• Dimensions (L x W x H): 1286 x 825 x 753 mm
• Designed for continuous operation in industrial applications
