Industrial bridge module TCPRS232IP
Add to favorites
Compare this product
Characteristics
- Type
- industrial
- Network
- IP, TCP, CAN, RS232
- Other characteristics
- DIN rail
Description
Our RS232 serial port node allows you to connect to control & service ports of your machinery. Superb isolation meets requirements of intrinsic safety level 'ia' or provides generic industrial isolation no less than 15kV, thanks to the solid 1.5mm thick FR4 isolation barrier.
Functionality
Logging to micro-SD card on gateway
Bus ID assigned via serial number
Configuration & firmware update via gateway
Possibility for custom firmware with specific protocol implementation
RS232 Interface node
Specifications
Serial port galvanically isolated from CAN-bus, 500V 'ia'-class isolation
5-Pin spring-contact termination for CAN, power and shield
Ground and shield and 'hazardous-GND' individually terminated to earth via 1nF class Y1 safety capacitors
Integrated mounting flanges (94mm wide), optionally without flanges
Two M16 brass cable gland entries in sides
Optional with 5-pole & 8-pole industrial M12 plug connections
