Isolated DC/DC converter IRT30

embeddedfor telecommunications equipmentvehicle

Product
The IRT30 is an isolated DC-DC converter module that converts a wide unregulated input (9–36V DC) to a regulated isolated 12V DC output rated at 30W.

Key features

• High-efficiency DC-DC converter (up to 90% at full load)
• Low inrush current for reliable startup
• Output over-current protection (OCP) and over-voltage protection (OVP)
• Wide input voltage range: 9–36V DC
• Electrical isolation between input and output

Certifications

• CE
• FCC

Overview
The IRT30 is designed for embedded, industrial and automotive environments where an isolated 12V rail and dependable startup behavior are required. Its modular DC-DC architecture supports higher power density and simplifies integration when multiple converters are deployed in a system.

Design and protection features
The converter uses a high-frequency Zero Voltage Switching (ZVS) topology to maintain consistent efficiency across the input range. Integrated protections include output over-current protection, over-voltage protection, short-circuit protection, thermal protection and low inrush characteristics to reduce stress on upstream power sources and downstream electronics.

Applications

• Automotive electronics and vehicle-mounted systems
• Industrial controllers, sensors and actuators
• Telecommunications and embedded OEM equipment requiring an isolated 12V rail

Product details

• Modular DC-DC system design to improve power density and reduce overall size when using multiple converters
• Regulated isolated 12V output from a fluctuating 9–36V input
• Designed for dependable startup with low inrush current
• Supports efficient point-of-load distribution from varied unregulated power sources

Technical specifications

• Input voltage: 9V to 36V DC
• Output: 12V DC, 2.5A (load range)
• Rated power: 30W
• Isolation: Yes (isolated converter)
• Ripple & noise: Less than 120 mV
• Line regulation: Less than ±1% at rated input
• Load regulation: Less than ±5%
• Efficiency: Up to 90% (full loading)
• Protections: OCP, OVP, short-circuit protection, thermal protection
• Certifications: CE, FCC
• Operating humidity: 10% to 90% RH, non-condensing
• Operating temperature: 0°C to 50°C
• Storage temperature: -20°C to 70°C
• Altitude: 0 to 10,000 ft
• Mechanical dimensions: 78.5 x 45 x 19.6 mm
