Lever micro-switch HK-14-16AP-605
single-poledust-proofstandard

Lever micro-switch - HK-14-16AP-605 - Yueqing Tongda Wire Electric Factory - single-pole / dust-proof / standard
Lever micro-switch - HK-14-16AP-605 - Yueqing Tongda Wire Electric Factory - single-pole / dust-proof / standard
Add to favorites
Compare this product
Go to the Yueqing Tongda Wire Electric Factory website for more information

Characteristics

Type
lever
Number of poles
single-pole
Protection level
UL, dust-proof, standard, IP40
Norms
ENEC, CQC
Other characteristics
AC, DC, action, industrial, plastic, reset, miniature, micro
Primary current

Min.: 5 A

Max.: 21 A

Voltage

125 V, 250 V

Diameter / length

27.8 mm
(1.1 in)

Operating temperature

Min.: -25 °C
(-13 °F)

Max.: 125 °C
(257 °F)

Width

10.2 mm
(0.4 in)

Height

18.7 mm
(0.7 in)

Description

Operating Parameter - Value - Units
Free Position FP - 15.9±0.2 - mm
Operating Position OP - 14.9±0.5 - mm
Releasing Position RP - 15.2±0.5 - mm
Total travel Position - 13.1 - mm
Operating Force OF - 0.25~4 - N
Releasing Force RF - — - N
Total travel Force TTF - — - N
Pre Travel PT - 0.5~1.6 - mm
Over Travel OT - 1.0Min - mm
Movement Differential MD - 0.4Max - mm

Current: 5(2)A,10(3)A,16(3)A,21(8)A
Voltage:AC 125V/250V, DC 12V/24V
Approved: UL,cUL(CSA),VDE,KC,ENEC,CQC

1. Sate, reliable basic switch
2. Nice appearance,tight contiguration.Charactenistic:small contact dlearance,quick action, high sensitivity and small 3.operating travel.
4. Long lite, high reliablity
5. A variety of contact terminals
6. A varnety of temperature degree
7. A variety of levers
8. Adopt themosetting plastic or themoplastic
9. Widely usedinhome apliane elecroninc equipmentautomatic machine communication equioncar electron,apparatus and instument,electric motion tool etc.
