Polishing vibratory finishing machine ZCV

deburringfinishingmetal

The ZDV Series – Round Type Drying Machines are designed to dry wet surfaces of parts after deburring and polishing processes. These machines also prevent corrosion of dried parts.

Features and Applications

• Suitable for drying processes after deburring and polishing.
• Uses corn granules for the drying process.
• Available in various volume options ranging from 125lt to 1650lt.
• Features a sieved structure.
• Operates with a resistance-heated system.
• Suitable for all types of materials, both metallic and non-metallic.
• Can be integrated into automation systems.
• Expandable with optional accessories.

Working Principle

• In drying machines, hot corn granules contact the part surface to absorb surface water.
• The resistance heating system increases drying speed, saving time and energy.
• Offers easy use with a material loading mouth and discharge slide.
• Parts are automatically brought to the discharge mouth with granules via the ramp inside the chamber and removed with the discharge slide.

Design and Safety

• Ergonomically designed chassis height and spring design provide high efficiency.
• Equipped with reinforced support construction against vibrations and adjustable isolators.
• Offers safe use with CE-certified electrical panels, main switch, and emergency stop switch.
• Standard equipment includes a working time control unit and timer.
• Uses a three-phase electrical connection.

Additional Features

• Can work integrated with PLC software automation systems.
• Optional dust extraction system available.
• Drying machine dimensions are designed to work integrated with previous process machines.

Characteristics / Technical Specifications

• Series: ZDV Series
• Type: Round Type Drying Machine
• Drying medium: Corn granule
• Volume options: 125lt – 1650lt
• Heating: Resistance
• Material compatibility: Metallic and non-metallic
• Automation: PLC integration and compatibility with automation systems
• Electrical connection: Three-phase
• CE-certified electrical panel
• Optional accessories and dust extraction system
